HSS Jobber Length Drills Wire Gauge (DIN 338)

Descriptions

General-purpose drill, to drill steels with tensile strength up to 1.000 N/mm2, cast steel, grey cast iron, malleable cast iron, nickel brass and graphite.

Specifications

No detailed specifications are available for this product.

Downloads

There are no downloads for this product.

Code	Description	Nominal Diameter	Series #	Surface Finish	Material	Flute Length	Overall Length	Price
0102051N	No.51 HSS DIN338 W/G JBR DRL	#51	01020	P1 Steam Tempered	HSS	22mm	46mm	You need to be logged in to see prices.
0102039N	No.39 HSS DIN338 W/G JBR DRL	#39	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
010203N	No.3 HSS DIN338 W/G JBR DRL	#3	01020	P1 Steam Tempered	HSS	57mm	93mm	You need to be logged in to see prices.
0102040N	No.40 HSS DIN338 W/G JBR DRL	#40	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
0102041N	No.41 HSS DIN338 W/G JBR DRL	#41	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
0102042N	No.42 HSS DIN338 W/G JBR DRL	#42	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
0102043N	No.43 HSS DIN338 W/G JBR DRL	#43	01020	P1 Steam Tempered	HSS	27mm	53mm	You need to be logged in to see prices.
0102044N	No.44 HSS DIN338 W/G JBR DRL	#44	01020	P1 Steam Tempered	HSS	27mm	53mm	You need to be logged in to see prices.
0102045N	No.45 HSS DIN338 W/G JBR DRL	#45	01020	P1 Steam Tempered	HSS	24mm	49mm	You need to be logged in to see prices.
0102046N	No.46 HSS DIN338 W/G JBR DRL	#46	01020	P1 Steam Tempered	HSS	24mm	49mm	You need to be logged in to see prices.
0102047N	No.47 HSS DIN338 W/G JBR DRL	#47	01020	P1 Steam Tempered	HSS	24mm	49mm	You need to be logged in to see prices.
0102048N	No.48 HSS DIN338 W/G JBR DRL	#48	01020	P1 Steam Tempered	HSS	24mm	49mm	You need to be logged in to see prices.
0102049N	No.49 HSS DIN338 W/G JBR DRL	#49	01020	P1 Steam Tempered	HSS	22mm	46mm	You need to be logged in to see prices.
010204N	No.4 HSS DIN338 W/G JBR DRL	#4	01020	P1 Steam Tempered	HSS	57mm	93mm	You need to be logged in to see prices.
0102050N	No.50 HSS DIN338 W/G JBR DRL	#50	01020	P1 Steam Tempered	HSS	22mm	46mm	You need to be logged in to see prices.
0102038N	No.38 HSS DIN338 W/G JBR DRL	#38	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
0102052N	No.52 HSS DIN338 W/G JBR DRL	#52	01020	P1 Steam Tempered	HSS	20mm	43mm	You need to be logged in to see prices.
0102053N	No.53 HSS DIN338 W/G JBR DRL	#53	01020	P1 Steam Tempered	HSS	20mm	43mm	You need to be logged in to see prices.
0102054N	No.54 HSS DIN338 W/G JBR DRL	#54	01020	P1 Steam Tempered	HSS	18mm	40mm	You need to be logged in to see prices.
0102055N	No.55 HSS DIN338 W/G JBR DRL	#55	01020	P1 Steam Tempered	HSS	18mm	40mm	You need to be logged in to see prices.
0102056N	No.56 HSS DIN338 W/G JBR DRL	#56	01020	P1 Steam Tempered	HSS	16mm	38mm	You need to be logged in to see prices.
0102057N	No.57 HSS DIN338 W/G JBR DRL	#57	01020	P1 Steam Tempered	HSS	14mm	36mm	You need to be logged in to see prices.
0102058N	No.58 HSS DIN338 W/G JBR DRL	#58	01020	P1 Steam Tempered	HSS	14mm	36mm	You need to be logged in to see prices.
0102059N	No.59 HSS DIN338 W/G JBR DRL	#59	01020	P1 Steam Tempered	HSS	12mm	34mm	You need to be logged in to see prices.
010205N	No.5 HSS DIN338 W/G JBR DRL	#5	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
0102060N	No.60 HSS DIN338 W/G JBR DRL	#60	01020	P1 Steam Tempered	HSS	12mm	34mm	You need to be logged in to see prices.
010206N	No.6 HSS DIN338 W/G JBR DRL	#6	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
010207N	No.7 HSS DIN338 W/G JBR DRL	#7	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
010208N	No.8 HSS DIN338 W/G JBR DRL	#8	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
010209N	No.9 HSS DIN338 W/G JBR DRL	#9	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
0102024N	No.24 HSS DIN338 W/G JBR DRL	#24	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102011N	No.11 HSS DIN338 W/G JBR DRL	#11	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
0102012N	No.12 HSS DIN338 W/G JBR DRL	#12	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
0102013N	No.13 HSS DIN338 W/G JBR DRL	#13	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102014N	No.14 HSS DIN338 W/G JBR DRL	#14	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102015N	No.15 HSS DIN338 W/G JBR DRL	#15	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102016N	No.16 HSS DIN338 W/G JBR DRL	#16	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102017N	No.17 HSS DIN338 W/G JBR DRL	#17	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102018N	No.18 HSS DIN338 W/G JBR DRL	#18	01020	P1 Steam Tempered	HSS	47mm	80mm	You need to be logged in to see prices.
0102019N	No.19 HSS DIN338 W/G JBR DRL	#19	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
010201N	No.1 HSS DIN338 W/G JBR DRL	#1	01020	P1 Steam Tempered	HSS	57mm	93mm	You need to be logged in to see prices.
0102020N	No.20 HSS DIN338 W/G JBR DRL	#20	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102021N	No.21 HSS DIN338 W/G JBR DRL	#21	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102022N	No.22 HSS DIN338 W/G JBR DRL	#22	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102023N	No.23 HSS DIN338 W/G JBR DRL	#23	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102010N	No.10 HSS DIN338 W/G JBR DRL	#10	01020	P1 Steam Tempered	HSS	52mm	86mm	You need to be logged in to see prices.
0102025N	No.25 HSS DIN338 W/G JBR DRL	#25	01020	P1 Steam Tempered	HSS	43mm	75mm	You need to be logged in to see prices.
0102026N	No.26 HSS DIN338 W/G JBR DRL	#26	01020	P1 Steam Tempered	HSS	39mm	70mm	You need to be logged in to see prices.
0102027N	No.27 HSS DIN338 W/G JBR DRL	#27	01020	P1 Steam Tempered	HSS	39mm	70mm	You need to be logged in to see prices.
0102028N	No.28 HSS DIN338 W/G JBR DRL	#28	01020	P1 Steam Tempered	HSS	39mm	70mm	You need to be logged in to see prices.
0102029N	No.29 HSS DIN338 W/G JBR DRL	#29	01020	P1 Steam Tempered	HSS	39mm	70mm	You need to be logged in to see prices.
010202N	No.2 HSS DIN338 W/G JBR DRL	#2	01020	P1 Steam Tempered	HSS	57mm	93mm	You need to be logged in to see prices.
0102030N	No.30 HSS DIN338 W/G JBR DRL	#30	01020	P1 Steam Tempered	HSS	36mm	65mm	You need to be logged in to see prices.
0102031N	No.31 HSS DIN338 W/G JBR DRL	#31	01020	P1 Steam Tempered	HSS	36mm	65mm	You need to be logged in to see prices.
0102032N	No.32 HSS DIN338 W/G JBR DRL	#32	01020	P1 Steam Tempered	HSS	33mm	61mm	You need to be logged in to see prices.
0102033N	No.33 HSS DIN338 W/G JBR DRL	#33	01020	P1 Steam Tempered	HSS	33mm	61mm	You need to be logged in to see prices.
0102034N	No.34 HSS DIN338 W/G JBR DRL	#34	01020	P1 Steam Tempered	HSS	33mm	61mm	You need to be logged in to see prices.
0102035N	No.35 HSS DIN338 W/G JBR DRL	#35	01020	P1 Steam Tempered	HSS	33mm	61mm	You need to be logged in to see prices.
0102036N	No.36 HSS DIN338 W/G JBR DRL	#36	01020	P1 Steam Tempered	HSS	33mm	61mm	You need to be logged in to see prices.
0102037N	No.37 HSS DIN338 W/G JBR DRL	#37	01020	P1 Steam Tempered	HSS	30mm	57mm	You need to be logged in to see prices.
